FL series DC Shunt is available to measure DC currents. This DC shunt can provide a proportional 50~100mV DC output to safely drive a moving coil instrument, overload protection, or other control device.
The manganin shunts have brass ends, available to measure currents from 0.1A up to 10000A, accurate to class 0.5, and are suitable for all DC current monitoring applications. Furthermore, various sizes, configurations, and mounting styles of DC shunt are available.
FL series DC Shunt is available to measure DC currents. This DC shunt can provide a proportional 50~100mV DC output to safely drive a moving coil instrument, overload protection, or other control device.
The manganin shunts have brass ends, available to measure currents from 0.1A up to 10000A, accurate to class 0.5, and are suitable for all DC current monitoring applications. Furthermore, various sizes, configurations, and mounting styles of DC shunt are available.
Applications of DC Shunt
| Color | Black & Silver & Yellow |
| Current Rating | 1~4000A: 0.5%;
5000~10000A: 1% (Default) |
| Accuracy | 0.5 / 0.2 (0.1 can be customized) |
| Voltage Tolerance | +/-0.5% |
| Voltage Drop | 50 mV /60 mV /75 mV /100 mV (customized) |
| Overload Capacity | 120% of nominal current (2 hours) |
| Operating Temperature | -40℃~60℃ |
| Shunt temperature when Load Current | <80°C (176°F) when load current <50A;
<120°C (248°F) when load current >50A |
| Material | Copper & Manganin |
