DZ47 Miniature Circuit Breaker

DZ47 Miniature Circuit Breaker

DZ47 AC MCB circuit breaker series is used in lighting distribution system or motor distribution system for protecting overload and short-circuit condition. The product is light in weightreliable and excellent in performance.

It has high breaking capacity up to 6kA. Its case and items are adopted with high fire-resistant and shock proof plastics. Mainly used in AC 50/60Hz single-pole 230V or two three four-pole 400V circuit for overload and short circuit protection as well as for on-off switching electric equipment and lighting circuit. The product complies with EN/IEC60898.

Category:

DZ47 AC MCB circuit breaker series is used in lighting distribution system or motor distribution system for protecting overload and short-circuit condition. The product is light in weightreliable and excellent in performance.

It has high breaking capacity up to 6kA. Its case and items are adopted with high fire-resistant and shock proof plastics. Mainly used in AC 50/60Hz single-pole 230V or two three four-pole 400V circuit for overload and short circuit protection as well as for on-off switching electric equipment and lighting circuit. The product complies with EN/IEC60898.

Category:

Specification

Rated current(In) 1A, 2A, 3A, 4A, 6A, 10A, 13A, 16A, 20A,
25A ,32A ,40A, 50A, 63A, 100A Optional
Rate voltage(Un) 230VAC / 415VAC / 400VAC / 415VAC Optional
Breaking capacity 6kA
Rated frequency 50/60Hz
Tripping charateristics BCD
Number of poles 1P, 2P, 3P, 4P, 1P+N, 3P+N Optional
Rated impulse withstand voltage(Uimp) 4kV
Electrical endurance 10000cycles
Mechanical endurance 10000cycles
Terminal Pillar type

Models

DZ47-NB-1P 1 pole contactor
DZ47-NB-2P 2 pole contactor
DZ47-NB-3P 3 pole contactor
DZ47-NB-4P 4 pole contactor
