OPT-R Rack Mounting Inverter

OPT-R Rack Mounting Inverter

OPT-R pure sine wave inverter is specially designed for electricity and communication systems. Inverter’s feature an integrated utility bypass and pure sine wave from a dc source. Suit for computers and other electrical equipment.

To prepare for the instability of the city electricity and power cuts. It also prevents various distortions of utility power, such as power supply voltage drop, surge voltage, spike voltage, and broadcast frequency interference.

OPT-R pure sine wave inverter is specially designed for electricity and communication systems. Inverter’s feature an integrated utility bypass and pure sine wave from a dc source. Suit for computers and other electrical equipment.

To prepare for the instability of the city electricity and power cuts. It also prevents various distortions of utility power, such as power supply voltage drop, surge voltage, spike voltage, and broadcast frequency interference.

Features

  • Pure sinewave includes Utility bypass & transfer.
  • Intelligent Microprocessor-Based Control.
  • 19Inch 1U/2U/4U Rack Mount.
  • Power Factor 0.8.
  • Low EMI/RFI Emissions.
  • User-Friendly LCD and LED Displays.
  • Default RS232 Communication port.
  • SNMP Communication Option.
  • IEC-60950 compliant.

Specification

Rated power 1KW ~ 10KW Optional
AC Input system 1Ph+N+PE
110~300VAC
DC Input 48VDC / 110VDC / 220VDC Optional
Voltage Output 110VAC / 220VAC, ±5% (Inverter mode)
50/60Hz±1%
Output wave Pure sine wave
THD<3%(linear load) Sine Wave THD<8%(nonlinear load)
Inverter switching time < 10ms (typical load)
Inverter efficiency > 85%
Output overload 110-120% @ 60s
120-150% @ 30s
Protection feature Battery overvoltage / low voltage, overload, short circuit protection, over temperature protection, Accept custumoerized
Operating temperature 0-40C (Storage -15 – +50C)
Machine Size 430 x 482 x 88mm (19′ rack, 2U height)

Selectable Models

Model OPT-R3 OPT-R4 OPT-R5 OPT-R6 OPT-R8 OPT-R10
DC Input Rated voltage* 24V/48V/110V/220V/240Vdc
Rated current** Depends on rated voltage
Working voltage range Depends on rated voltage
Reverse noise Current ≤10%
AC Bypass input Allow voltage 220Vac±20%
Current 10.8A 14.5A 18.2A 21.8A 29A 36A
Conversion interval ≤5ms
AC Output Capacity* 3KVA 4KVA 5KVA 6KVA 8KVA 10KVA
Power 2400W 3200W 4000W 4800W 6400W 8000W
Voltage & frequency 220Vac±3% & 50Hz±0.1%
Current 10.8A 14.5A 18.2A 21.8A 29A 36.3A
THD ≤3% @Linear load
Dynamic Response 5% @Load 25%~100%
Over load ability 10mins @100%~125%; 15seconds @125%~150%;
Shut down immediately over 150%
Efficiency ≥85% @80% Resistive load
Others Insulation strength 1500Vac, 1min (input and output)
Noise ≤40dB@1meter distance
Operating temperature  -25°C~+50°C
Humidity 0~90%, no cooling
Altitude ≤1000m
Weight/Kg 12kgs 13kgs 14kgs 15kgs 20kgs 22kgs
Protect function Input lower voltage, input overvoltage protection; output overload protection, output short circuit protection

Notes:
* AC output with ±100W error of the rated capacity
**DC input extension table:

Rated voltage 24Vdc 48Vdc 110Vdc 220Vdc 240Vdc
Working voltage range 20V~30.5V 40V~58.8V 90V~145V 180V~270V 200V~300V
Start up / Boot voltage range 21.5V~29.5V 42V~57V 94V~142V 190V~265V 210V~295V
Rate current input  @3 KVA 117A 57A 24.9A 12.4A 11.7A
 @4 KVA / 77A 33.4A 16.7A 15.6A
 @5 KVA 98A 36.6A 18.3A 19.6A
 @6 KVA 117A 51.3A 22A 23.5A
 @8 KVA 156A 68A 34.2A 34.2A
 @10 KVA 196A 85A 42.7A 39A
