194E LED Digital Power Meter

194E LED Digital Power Meter

194E is extrem low cost solution for power line parameter monitor, It’s equipped 3 line LED disply. Visual display of the modt commonly used data. It is widely used in metering of distribution feeders transformers generators capacitor banks and motors.

194E is extrem low cost solution for power line parameter monitor, It’s equipped 3 line LED disply. Visual display of the modt commonly used data. It is widely used in metering of distribution feeders transformers generators capacitor banks and motors.

Features

  • Class 0.5 for basic power parameter
  • LED screen display 3 lines 4 digits
  • 96*96mm panel mounting size
  • ITF Technology: galvanic insulation protection inputs outputs

Specifications

Power Supply AC / DC 80-265V, 45-65Hz
Burned < 10VA
Current Measurement …/ 1A or …/5 A
Burned < 0.1W
Voltage Measurement Direct measurement 18~277V ac (L-N)
PT secondary …/100Vac
Burned < 0.1W
Frequency Measurement 45~65Hz
Resolution 0.01Hz
Accuracy U / I / P/ Q – 0.5%
Frequency – 0.1%
Active Energy – 1.0 class
Reactive Energy – 2.0 class
Communication Port RS485 (2/3 wires half duplex)
Modbus RTU mode
Pulse Outputs 2 channel Coupler relay

Selectable Models

Download

Brochure of Multi-Function Power Meter

BJ194E-9SY Usermanual V1.5
